Intra-volume marking
Intra-volume marking with the laser makes it possible to locally modify the refractive index of transparent materials. This modification allows you to inscribe 3D patterns to functionalize or to create a decorative effect in the material.
The characteristics of the intra-volume marking process:
Benefits
- Localized
- Dust free
- High 3D resolution
- Colour variation
Performance
- Variation in index up to 0.01 depending on the materials
- Precision of 1 μm in XYZ directions
- Custom 3D patterns
Throughput
- Processing speed: up to 100 mm.s-1 for index change
- Colouring process speed: 1.5 m.s-1
Laser workstation
- Pulses: femtosecond, picosecond and nanosecond
- Wavelengths: infrared and visible
- Numerical aperture from 0.2 to 0.4
- DXF, JPEG implementation
Surface condition
Unmodified surface
Materials used for intra-volume marking:
- Polymer
- Organic glass
- Doped glass
- Industrial glass
Process sheet
Areas of application
- Phase mask
- Optical microscopy
- Ophthalmic optics
- Anti-counterfeiting
- Bottle making
- Watchmaking
- Automobile
