Tombak: Pulse Delay Generator
This pulse delay generator generates high frequency pulses, digital delays and bursts. It is an ideal synchronization and timing control instrument for electronics and lasers. Tombak can be used as a standalone generator, digital delay generator, 150 MHz voltage level converter, AWG (Arbitrary Waveform Generator), frequency divider, pulse picker or burst generator.
It is the most compact device with such performances and this makes it an ideal tool for OEM integration into your product. Applications of this pulse delay generator include component testing, laser timing control, laser pulse-picking and laser diode pulsing.
Product reference: Tombak
Key features
- 10 ps delay resolution
- 2 ns pulse resolution
- 80 ps RMS jitter
- Min input voltage: 30 mV
- 150 MHz voltage level converter
- 20 MHz standalone generator
- Burst/gate generator
- USB interface
- 2 years warranty
The GUI software lets the user have total control of all module functions. It includes several libraries for software integration (Labview VIs, DLLs, Hexa etc.).
Applications
- Ideal for OEM integration
- Components test
- Laser timing control
- Laser pulse-picking
- Precision pulse application
- Instrument triggering
- ATE applications
